Referencia interna:
4503959
Marca:
TUNGALOY
| ESPECIFICACIONES TÉCNICAS | |
|---|---|
| Tipo de producto | Portaherramienta |
| Categoría técnica | Shrink Fit Holders |
| Familia / sistema | CAT-SRKIN (TungShrink) |
| Aplicación | Tapered shape interface |
| Material | Acero |
| Sistema de medida | Pulgadas |
| Longitud total (OAL) | 3-1/2" |
| Connection Diameter Workpiece Side (DCONWS) | 0.313" |
| Tipo de mango | Round |
| Shank Size (SS) | 40. |
| Body Length (LB) | 2-3/4" |
| Thread Designation Inside (THID) | M6 |
| Body Length_2 (LB_2) | 2.12" |
| Body Diameter (BD) | 0.827" |
| Body Diameter_2 (BD_2) | 1.063" |
| Unidad | I |
